This is the COMPLETE Technical Manual for the John Deere 1133, 1144, 1155, 1157, 1158 Combines. It contains deep information about maintaining, assembly, disassembly and servicing your John Deere 1133, 1144, 1155, 1157, 1158 Combines.

This manual contains information and data to this model. Has specs, diagrams, and actual real photo illustrations, color schemes. These technical manual is as good as it gets for Diagnosing, Repairing, and Maintenancing John Deere machinery.

Models Covered:
=========
John Deere 1133 Combines
John Deere 1144 Combines
John Deere 1155 Combines
John Deere 1157 Combines
John Deere 1158 Combines

Technical Manual Contains:
=========
SECTION 10 – GENERAL
Group 05 – Specifications
SECTION 20 – ENGINE REPAIR
Group 05 – Removal and Installation, 4-cyl. Engine
Group 10 – Removal and Installation, 6-cyl. Engine
SECTION 30 – FUEL AND AIR REPAIR
Group 05 – Fuel Filter With Water Trap And Electrical Fuel Transfer Pump
SECTION 40 – ELECTRICAL SYSTEM REPAIR
Group 05 – Connectors
Group 10 – Electrical System Components
Group 15 – Starting Motor
Group 20 – Alternator
Group 25 – Low Shaft Speed Monitor System
Group 30 – Electromagnetic Transmission Brake
SECTION 50 – POWER TRAIN REPAIR
Group 05 – Variable Ground Speed Drive
Group 10 – Engine Clutch And Mechanical Clutch Operation (3-Speed Transmission)
Group 15 – Engine Clutch Operation (4-Speed Transmission)
Group 20 – Engine Clutch Operation (4-Speed Transmission)
Group 25 – Three-Speed Transmission
Group 30 – Four-Speed Transmission With Differential
Group 35 – Final Drives, Differential (3-Speed Transmission)
Group 40 – Final Drives (4-Speed Transmission)
Group 45 – Final Drive On Rice Combine (4-Speed Transmission)
SECTION 60 – BRAKES, REAR AXLE AND STEERING REPIAR
Group 05 – Parking Brake (3-Speed Trnsmission)
Group 10 – Parking Brake (4-Speed Transmission)
Group 15 – Brake Operation
Group 20 – Foot Brakes (3-Speed Transmission)
Group 25 – Foot Brakes (4-Speed Transmission)
Group 30 – Foot Brakes With Integrated Slave Cylinder
Group 35 – Hydrostatic Steering Unit
Group 40 – Rear Axle
Group 45 – V-Support For Wide Rear Axle
Group 50 – Steering Cylinder
SECTION 70 – HYDRAULIC SYSTEM REPAIR
Group 05 – Hydraulic Oil Reservoir And Lines
Group 10 – Hydraulic Pump
Group 15 – 4-Spool Control Valve With Flow Divider
Group 20 – Hydraulic Cylinders
Group 25 – Hydraulic System Diaphragm-Type Accumulator
SECTION 80 – MISCELLANEOUS
Group 05 – Bearings And Shafts
Group 10 – Drive Belts
Group 15 – Drive Chains
Group 20 – Specifications, Special Tools, and Torques
SECTION 90 – OPERATOR’S PLATFORM WITH CAB
Group 05 – Safe Handling Of Refrigerants
Group 10 – Air Conditioning Compressor
Group 15 – Air Conditioning System Components
Group 20 – Air Conditioning System Service And Tests
Group 25 – Cab Ventilation System
Group 30 – Cab Heating System
Group 35 – Operator’s Cab
Group 40 – Control Levers
Group 45 – Operator’s Seat
SECTION 100 – CUTTING PLATFORM AND CORN HEAD
SECTION 110 – FEEDER HOUSE
Group 05 – Feeder House Drive
Group 10 – Feeder House With Compact Cutting Platform
Group 15 – Feeder House With Quick-Tach Cutting Platform
SECTION 120 – SEPARATOR AND CLEANING UNIT
Group 05 – Stone Trap
Group 10 – Separator Drive
Group 15 – Variable Cylinder Drive
Group 20 – Threshing Cylinder
Group 25 – Concave
Group 30 – Beater Variable Drive
Group 35 – Beater
Group 40 – Cross Shaker
Group 45 – Straw Walkers
Group 50 – Cleaning Shoe, Grain Return Pan And Auger Housing
Group 55 – Fan And Variable Speed Drive
SECTION 130 – GRAIN PROCESSING
Group 05 – Clean Grain And Tailings Augers
Group 10 – Clean Grain Elevator
Group 15 – Tailings Elevator
Group 20 – Upper Tailings Auger
Group 25 – Grain Tank Leveling Auger
Group 30 – Grain Tank Center Fill Auger
Group 35 – Inner Grain Tank Unloading Auger
Group 40 – Outer Grain Tank Unloading Auger
Group 45 – Discharge Tube
SECTION 140 – SPECIAL EQUIPMENT
Group 05 – Straw Chopper Drive
Group 10 – Straw Chopper Rotor Bearings
SECTION 220 – ENGINE OPERATION
SECTION 230 – FUEL AND AIR INTAKE SYSTEM OPERATION
Group 05 – General Information, Fuel Filter And Fuel Transfer Pump
SECTION 240 – ELECTRICAL SYSTEM – OPERATION AND TESTS
Group 05 – General Information
Group 10 – Circuit plan, Wiring Diagram And Wiring Harnesses
Group 15 – Checking Indicator Lights
Group 20 – Checking Low Shaft Speed Monitor System
Group 25 – Checking Straw Warning Device
Group 30 – Checking Electromagnetic Transmission Brake
SECTION 250 – POWER TRAIN – OPERATION AND TESTS
Group 05 – Engine Clutch And Operation (3-Speed)
Group 10 – Engine Clutch And Operation (4-Speed)
Group 15 – Three-Speed Transmission
Group 20 – Four-Speed Transmission
SECTION 260 – BRAKES, REAR AXLE AND STEERING – OPERATION AND TESTS
Group 05 – Brake Operation
Group 06 – Foot Brake And Operation (Combines With Rice Equipment)
Group 10 – Operation And Flow Diagram 0 Hydrostatic Steering
Group 15 – Diagnosing Steering System Malfunctions
Group 20 – Primary (Steering) Circuit Testing
SECTION 270 – HYDRAULIC SYSTEM – OPERATION AND TESTS
Group 05 – Hydraulic Circuit Symbols
Group 10 – Hydraulic Lift Circuit
Group 15 – Lifting System – Diagnosing Malfunctions
Group 20 – Hydraulic Lift Circuit – Testing
SECTION 290 – OPERATOR’S PLATFORM AND CAB – OPERATION AND TESTS
Group 05 – Cab Venilation System
Group 10 – Air Cinditioning System
Group 15 – Safe Handling Of Refrigerants
Group 20 – Testing Air Conditioning System
Group 25 – Cab Heating System

==========
